Proteins are organic biopolymers consisting of a sequence of smaller amino-acid units. However, unlike synthetic polymers, which are made from a single monomer repeated over and over, these amino acids come from a library of 20 different varieties, enabling proteins to fold into complex three-dimensional (3D) shapes that directly control their function. The research led by James J. De Yoreo and David Baker from the Pacific Northwest National Laboratory and the University of Washington, and published in a recent issue of Nature focus on the self-assembly of proteins in the presence of crystals. Indeed, from ice-binding proteins to bone formation, there are indications showing that proteins and minerals can show strong binding affinity and play a role in the mineralization process.

To study the binding of proteins to mineral surfaces, the team designed proteins that specifically bind to mica and self-assemble into ordered patterns on this surface. This binding is driven not only by electrostatics, but also via the specific 3D shapes that proteins adopt in liquid, to allow the carboxyl groups on the protein to match the crystal lattice. Therefore, to design the protein, they used a preexisting helical repeat protein (DHR) whose repeat unit is close to the spacing of the target mica lattice, namely 1.04 nm. The main hypothesis that the researchers validated is that for a protein to adsorb in a predictable orientation onto the surface, the carboxylate groups of the protein should be spaced with the same distances as the atoms of the surface.

First, the researchers used simulation tools to predict which protein sequence with the DHR repeat unit is required to achieve this specific binding. This sequence was then used to modify the DNA of a bacteria that was cultured to produce the artificially designed protein in vivo. After separation and purification of the protein, they used atomic force microscopy (AFM) to visualize the self-assembled protein structures onto mica. In a typical experiment, the protein solution was deposited onto the mica surface in the presence of K⁺ ions. These ions play an important role in defining the interactions between the protein and the surface, which in turn impacts their assembly into designed structures. Scanning the surface with AFM, they observed the formation of liquid-crystal-like assemblies that depended on the ion concentration and the protein sequence. By incorporating protein–protein interactions, they could design, model, and fabricate various kinds of assemblies, including coaligned single protein nano-wires and hexagonal lattices (see Figure).

Akshita Kumar Dhawan, a post-doctoral researcher at the Centre for Biomimetic Sensor Science at the Nanyang Technological University in Singapore who did not participate in the study, comments that it is “an impressive demonstration of conceiving such degree of control over structured protein–mineral interfaces at various length scales, and the possibility to tailor design them. This is certainly a milestone study that opens multiple avenues in materials and structural biology research.” She adds, “Although an intriguing question is the role of water and salts in the packing of the proteins on the surface.” Actually, Harley Pyles and Shuai Zhang, the first authors of the study, explain that this is the focus of a future manuscript currently under preparation.

With this work, De Yoreo, Baker, Pyles and Zhang, the four authors, dream “to achieve the same capability of control as found in bones but for functional materials such as semiconductors and photovoltaics, including the ability to drive the morphogenesis of multiple types, such as p- and n-types or acceptors and donors.” Baker says, “Being able to design such systems de novo may enable self-assembling architectures of such materials at high packing density in 3D.”

Originally published in the September 2019 issue of MRS Bulletin.
